oem epen plastic foam sheet extrusion machine for making packing mattress
polystyrene foam sheet extrusion machine
EPE foam machine can make different foam sheet width and thickness according to customer requirement. Meanwhile, it can also make foam pipe, foam net, foam rod, foam profile and so on through changing mould and machine parts.
The foam sheet has the features of dampproof , shockproof, soundproof, heat preservation and good plasticity. After laminating, the foam sheet will get high dampproof performance. These products are mainly used for placing under floor.
|
Model | Unit | EPE90 | EPE105 | EPE120 | EPE150 | EPE170 |
Screw diameter L/D |
| 90/55:1 | 105/55:1 | 120/55:1 | 150/55:1 | 170/55:1 |
Screw speed | r/min | 5-45 | 5-45 | 5-45 | 5-45 | 5-45 |
Foam rate |
| 20-40 | 20-40 | 20-40 | 20-40 | 20-40 |
Width of product | mm | 1000-1400 | 1000-1500 | 1000-2000 | 1000-2000 | 1000-2000 |
Thickness of product | mm | 0.5-4.5 | 0.5-6.5 | 0.8-8 | 1-12 | 2-16 |
Cooling method |
| cooled by water | ||||
Installed capacity | kw | 90 | 100 | 120 | 150 | 180 |
Dimensions(L×W×H)(approx) | m | 22×2.3×2.2 | 23×2.3×2.2 | 25×2.3×2.2 | 30×2.3×2.2 | 32×2.3×2.2 |
Total weight(approx) | t | 8.5 | 9 | 12 | 15 | 17 |
Applicable Industries:
Manufacturing Plant
Screw diameter (mm):
90 mm
Screw Material:
38GrmoAlA
Screw L/D Ratio:
55:1
Output (kg/h):
70 - 100 kg/h
Condition:
New
Application:
Sheet, Film
Plastic Processed:
PE
Screw Design:
Single-screw
Place of Origin:
Shandong, China
Brand Name:
DEYI
Voltage:
380V 50HZ
Dimension(L*W*H):
22M*2.3M*2.2M
Weight:
8.5T
Certification:
ISO CE
Power (kW):
110
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty:
1 Year, 1 Year
Key Selling Points:
Multifunctional
Name:
epe foam packing sheet making machine in plastic extruder
Usage:
Package
Material:
38CrMoAlA
Raw material:
PE Granules
Capacity:
70-100KG/H
Product:
Sheet Production
Processing Type:
Exturding Machine
Product Type:
Pe Film
